Frequently asked questions about Leica Geosystem's range of digital levels What are the main advantages of an electronic level compared to an optical one? With optical levels it happens many times that you do not read out correctly. The electronic level eliminates such errors. Furthermore, digital levels such as the automatically calculate the height differences based on your measurements.

Leica Sprinter 250M & 150M Digital Levels. Digital levels with the highest performance and on-board memory. Improve your workflow and increase your productivity with the Leica Sprinter M levels. All measurements are stored in the appropriate order and can be downloaded to a PC for further use in Microsoft Excel. The different calculation.

What is the typical measuring time? For all models, the typical electronic measuring time is 2-3 seconds in normal daylight condition. Measuring time will be slightly longer with uniform dim light condition, for instance in the late evening or under a street light at night. What is the accuracy of the? The ISO double-run electronic accuracy for are 2.0mm / 1.5mm / 1.5mm / 1.0mm respectively.

For all the models, the ISO double-run optical accuracy is 2.5mm. What is the shortest focusing distance? The shortest optical focusing distance is 50 cm for all of the models.

Free mp3 320kbps download. Download to all audio songs of Cricket 2018 malayalam movie. 2 song was released. Music by: Krishan Lal Singers: Madhu Balakrishnan, Krishna Lal Lyrics: Sreejith Rajan Information Cricket 2018 Malayalam Movie Songs Download MP3 Title 128Kbps 320Kbps 1. Sachin Anthem Madhu Balakrishnan Download 0.99 MB Download 2.37 MB 2.

This short focusing distance comes in handy when working in a narrow confined space. What is the maximum measurable distance?

All of the models are able to measure electronically from 2 m to 100 m with a Sprinter standard aluminum barcode staff. Does the Leica Sprinter only operate with GSS staffs? Yes, the attached barcode on GSS staffs is only valid for. What are the onboard functions available for? Is the basic ‘one-touch’ model available with Height & Distance measurement capability, on-board electronic Line of Sight Adjustment program, auto-recognition of staff orientation, tilt warning and preset units setting in meter or US feet (regional dependent). What are additional features of the? Is a medium range model available with Height-Difference measurement capability and operating functions such as LCD display contrast, units, auto-off, rounding, audio beep, tilt warning, LCD display back light, measurement averaging and MMI language selection can be easily access via the user-friendly menu.

Does the instruments have onboard data storage? Yes, are able to store measured field data to the onboard storage. What are additional features of the top range? Are the more advanced models with onboard and well-guided applications such as line leveling, cut & fill and timer function for monitoring work. Measurement can be recorded to the onboard storage or externally to a data logger via RS232 cable.

Onboard stored data can be easily downloaded directly to a PC via USB cable. One click and the data is transferred immediately to Microsoft Excel. What is the main purpose of the internal memory of the? If you execute a line leveling or an area leveling job, you do not have to write down all measurement results.

This saves a lot of time. Furthermore, back in the office, you just transfer your data from the instrument storage directly into Excel where all results are presented in appropriate order for post-processing.

How can the data be downloaded from? Measurement data can be downloaded from to PC: A) via Leica Sprinter USB cable to Leica Sprinter DataLoader B) via RS232 cable to Leica Geo Office LGO or Microsoft Hyper-terminal program In which PC operating system environment the DataLoader is executable?

DataLoader is executable on Microsoft Windows Vista, XP, 2000 and 98. For data downloading, can this data be downloaded with all versions of Microsoft Excel? Data can be downloaded to Excel versions 2007, 2003, 2002 and 2000 (versions 12 - 9.0).

What is the idea of the new Cut & Fill application on? This very useful onboard application will help you to check heights compared to a design level. For example, excavation: The print indicates the designed excavation level. You can now check easily if the designed level is already achieved by taking measurements. The software will immediately present cut and fill results (height differences between design level and measured height). Any protection against water, dust and sand? Yes, All the models meet the environment specification IP55 (IEC 60529) for protection against water, dust and sand.

Can I use an external power supply for Leica Sprinter instead of 4 AA dry cells? Yes, you can power with GEV71 external power pack with RS232 cable from Leica Geosystems. How long can 4 AA dry cells last with continuous operation of the instrument?
